MECHANICAL SPECIFICATION

Format

1791mm x 1052mm x 30mm

Weight

24.0kg±3%

Cell

120 monocrystalline cells

Junction Box

IP68

Cable

4mm²

Nominal Max. Power (Pmax)

360W

365W

Open Circuit Voltage (Voc)

41.3V

41.5V

Short Circuit Current (Isc)

11.11A

11.18A

Opt. Operating Voltage (Vmp)

34.3V

34.5V

Opt. Operating Current (Imp)

9.48A

9.55A

Module Efficiency

19.1%

19.4%

Reference To 355W Front

Backside Power Gain

5%

10%

15%

20%

25%

Nominal Max. Power (Pmax)

373W

391W

408W

426W

444W

Open Circuit Voltage (Voc)

41.1V

41.1V

41.2V

41.2V

41.2V

Short Circuit Current (Isc)

11.59A

12.14A

12.70A

13.25A

13.80A

Opt. Operating Voltage (Vmp)

34.1V

34.1V

34.2V

34.2V

34.2V

Opt. Operating Current (Imp)

10.94A

11.46A

11.98A

12.50A

13.03A

PACKAGING

Model

LR4-60HBD 360-365M

Model per Pallet

35 pieces

Note: The above packing information contained in this web is subject to change without notice. We will offer wooden box packing with extra material and labor costs if your order less than a pallet, we accept any customized packing as per your requests.

MECHANICAL SPECIFICATION

Format

2094mm x 1038mm x 35mm

Weight

27.5kg±3%

Cell

144 monocrystalline cells

Junction Box

IP68

Cable

4mm²

Nominal Max. Power (Pmax)

440W

445W

Open Circuit Voltage (Voc)

49.2V

49.4V

Short Circuit Current (Isc)

11.45A

11.52A

Opt. Operating Voltage (Vmp)

41.0V

41.2V

Opt. Operating Current (Imp)

10.73A

10.80A

Module Efficiency

20.2%

20.5%

Reference To 445W Front

Backside Power Gain

5%

10%

15%

20%

25%

Nominal Max. Power (Pmax)

467W

490W

512W

534W

556W

Open Circuit Voltage (Voc)

49.4V

49.4V

49.5V

49.5V

49.5V

Short Circuit Current (Isc)

12.06A

12.67A

13.24A

13.82A

14.40A

Opt. Operating Voltage (Vmp)

41.2V

41.2V

41.3V

41.3V

41.3V

Opt. Operating Current (Imp)

11.34A

11.88A

12.42A

12.96A

13.50A

PACKAGING

Model

LR4-72HBD 440-445M

Model per Pallet

30 pieces

Note: The above packing information contained in this web is subject to change without notice. We will offer wooden box packing with extra material and labor costs if your order less than a pallet, we accept any customized packing as per your requests.
